It is European warehouse price — ready to ship from EU stock, Ex-Works Europe (EXW).
The industrial and commercial storage products feature a modular system design, available in economic and standard models. The economic models are compact with high energy density, while the standard models offer excellent energy and power adaptability with flexible configuration options. These products facilitate peak shifting, staggered power consumption, and help alleviate grid pressure.
Electrical Parameters |
|
| Cell Type | LFP-300Ah |
| Grouping cycle life | >8000 |
| Rated Voltage (Vdc) of Single Cell | 3.2 |
| Pack Configuration | 1P44S |
| Rack Configuration | 1P220S |
| System Configuration | 1P220S |
| System Nominal Energy (kWh) | 211 |
| System Rated Voltage (Vdc) | 704 |
| System Voltage Range (Vdc) | 600-803 |
| System Output Voltage (Vac) | 400@50Hz/60Hz |
| System Rated Power (kW) | 100 |
| Charge / Discharge Rate | 0.5P@25° C |
Components |
|
| High Voltage Box | Integrated in Control Box |
| Confluence Cabinet | Integrated in Control Box |
| Monitoring System (HMI) | Integrated |
| Fire Suppression System | Temperature/Smoke detection
+gas concentration detection +explosion relief panel +Aerosol |
| Thermal Management System | Integrated Liquid Cooler(5kW cooling capacity)+ Air-cooling for PCS |
Conditions |
|
| Storage Temperature (° C) | -30~60 |
| Working Ambient Temperature (° C) | -20~45 (>45 Derating) |
| Working Relative Humidity (%) | 0~95 (Non-condensing) |
| Working Altitude (m) | ≤ 2000 (>2000 Derating) |
Other Parameters |
|
| Max. Parallel Sets | 20(grid-connected), 4(off-grid) |
| Ingress Protection | IP55 |
| Communication Interface | 4G*, RS-485, Ethernet(reserve) |
| Communication Protocol | Modbus RTU/MQTT |
| Dimensions (L*W*H) mm | 1340×1300×2260 |
| Weight (t) | ≈ 2.6 |
Standards & Certification |
|
| UL | UL9540A (pack) |
| IEC | IEC 62477-1, IEC 61000-6-2,IEC 61000-6-4, IEC 63056
IEC 62619, IEC 60730-1 |
| Transportation | UN38.3, UN3480 |
| Color | Brown |
|---|
